Overall Static Free Fabric 20D Trefoil Carbon Composite Conductive Polymer Nylon Filament

Product Details:
Place of Origin: China
Brand Name: Huaiying
Model Number: N32-20D-3F
Payment & Shipping Terms:
Minimum Order Quantity: 100kgs
Price: Negotiation
Packaging Details: carton box + pallet
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 1500kgs per month

Detail Information

Yarn Count: 20±0.5 Dtex Strength: 3±0.3 CN/Dtex
Hole Count: 3F Elogation At Break: 60~90 %
Electrical Resistivity: 1.2~5 X 10^6 Ω/cm Material: Nylon 6 + Carbon Black Particle
Boiling-water Shrinkage Ratio: 10±2.0%
High Light:

non static fabric


anti static polyester fabric

Product Description

Overall Anti Static Fabric 20D Trefoil Carbon Composite Conductive Polymer Nylon Filament



20D trefoil carbon composite conductive polymer nylon filament for anti-static overall is that a large number of conductive carbon black particles in nylon form tunnel effect, and then through the composite spinning process to achieve permanent conductivity. Not only has good electrical conductivity, but also has the mechanical and textile properties of common synthetic fiber, which is convenient for the application and processing of fiber.
Composite conductive fiber is widely used in anti-static clothing, anti-static clean fabric, lining and anti-static shoes, hats, gloves and other fields because of its good washing resistance, abrasion resistance, bending resistance and so on. Carbon particles on the surface will not fall off because of washing and friction, and the excellent properties of contact surface also will not be decreased like metal fiber due to break down or fall off.


Application field:

microelectronics industry anti-static clothing; Anti-static clean clothes; Medium and high grade clothing lining silk; anti-static overall of oil field, coal mine, gas station, gas field, chemical plant, etc.; explosion-proof working clothes for military industry; anti-static glove, socks; carpet, wool, filter materials, etc.


Overall Static Free Fabric 20D Trefoil Carbon Composite Conductive Polymer Nylon Filament 0



Overall Static Free Fabric 20D Trefoil Carbon Composite Conductive Polymer Nylon Filament 1


Composition: Nylon 6 + carbon black particle

Linear density: 20±0.5 Denier

Filament: 3F

Tensile strength: 3.0±0.3 cN/Dtex

Boiling-water shrinkage ratio: 10±2.0%

Elongation at break: 60~90 %

Electrical resistivity: 1.2~5 x 106 Ω/cm

Color: black
